HA OSH 11-200 LED Obstruction light

Description

An obstruction is a fixed object that extends above an obstacle protection surface and shall be lighted if a runway is used at night.

The marking and/or lighting of obstacles is intended to reduce hazards to aircraft by indicating the presence of the obstacles.

Low-intensity obstacle lights, Type A or B, should be used where the object is a less

extensive one and its height above the surrounding ground is less than 45 m.

Led technology Atex IECEx zone 2. This Obstruction light is suitable for landbase use and also for offshore use.

Our OSH 11 type Low intensity obstruction light with glass fresnel lens, complying both to CAP437 and ICAO Annex 14 class A and B ( 10 Cd and 32 Cd)

Enclosure	Aluminium, chromated and hot baked powder coated
Light Output	>200 Cd
Light Source	High power LED
Service life of the LED's	> 75.000 Hours
Dimensions	230x160x195 mm
Cable Gland	2x M20
Ambient Temperature	-40˚ C to + 60˚ C
Ingress Protection	IP 67
Optional	Flashing 30, 60, 90 or 120 Fpm
Power supply	110-240 Vac, 12-24 Vdc
Power consumption	Max. 50 Watt
Compliances	ICAO Annex 14 Vol I, ICAO Annex 14 Vol II., UK CAP 168, UK CAP 437, Atex zone 2 ATEX/IECEx II 3 G Ex nA IIC T5
